Hyundai 940TM Loader
The Komatsu 940TM wheel loader is comfortable, efficient and productive, making it an operator favorite. A travel speed of 40 km/h forwards and 26.1 km/h in reverse makes this loader more effecient on-site. An integrated rear view camera, viewable through the widescreen monitor, helps with safety and precision. Ideal for use in agriculture, forestry, oil & gas, public works, road construction, scrap yards, utilities, waste, and more.
Power: Equipped with a 2.3 cubic meter bucket and 156hp, this wheel loader delivers maximum performance, capable of loads of up to 16,310 pounds. The bucket breakout force is 23,880lbs.
Dump Height: 2,840mm (9 ft 3 inches)
Efficiency: The eco pedal helps to reduce fuel burn when throttling between zero and 85% of full power. The operator can adjust settings for tougher jobs, increasing the eco pedal to run at 100% of available power.
Comfort: Cabs on the HL 940TM are 10% larger than previous models, offering superior floor space and improved visibility. The HL940TM has one of the quietest cabs in the industry. The cab features a heated air-ride seat that is fully customizable based on the operator's preferences.
|Engine Model||Cummins QSB6.7|
|Net Power||156 hp (116kW) at 2,100 rpm|
|Maximum Torque||86 kgm (622 lb ft) / 1500 rpm|
|Operating Weight||13,600kg (29,980 lbs)|
|Bucket Capacity (Heaped)||2.3 cubic meters|
|Bucket Breakout Force||10,830 kg (23,880 lbs)|
|Full turn tipping load||7,400 kg (16,310 lbs)|
|Travel speed forward||40 km/h|
|Travel speed reverse||26.1 km/h|
|Dump clearance with bucket||2,840 mm (9ft 3 inches)|
